Intel
®
Server Board S5400SF TPS System BIOS
Revision 2.02
Intel order number: D92944-007
91
5.2.3.2.4 Mass Storage Controller Screen
The Mass Storage screen provides fields to configure when a SAS controller is present on the
server board, midplane or backplane of an Intel
®
system.
To access this screen from the Main menu, choose Advanced > Mass Storage.
Advanced
Mass Storage Controller Configuration
SAS Controller Enabled/Disabled
Configure SAS as SW RAID Enabled/Disabled
Figure 23. Setup Utility — Mass Storage Controller Configuration Screen Display
Table 36. Setup Utility — Mass Storage Controller Configuration Screen Fields
Setup Item Options Help Text Comments
SAS Controller Enabled
Disabled
Enable or Disable the on-board
Serial Attached SCSI (SAS)
Controller.
Configure SAS as SW
RAID
Enabled
Disabled
SAS ports are configured for
Intel
®
Embedded Server RAID
Technology.
This item is unavailable if the device
is disabled.
5.2.3.2.5 Serial Ports Screen
The Serial Ports screen provides fields to configure the Serial A [COM 1] and Serial B [COM2]
ports.
To access this screen from the Main screen, choose Advanced > Serial Port.
