System BIOS Intel
®
Server Board S5400SF TPS
Revision 2.02
Intel order number: D92944-007
90
Setup Item Options Help Text Comments
AHCI Mode Enabled
Disabled
Advanced Host Controller
Interface (AHCI) option ROM will
enumerate all AHCI devices
connected to the SATA ports.
Contact your OS vendor
regarding OS support of this
feature.
This item is unavailable if the
SATA mode is “Legacy” or if the
RAID Mode is selected.
When AHCI is enabled:
The identification and
configuration is left to the AHCI
Option ROM. Only devices
supported by the AHCI Option
ROM are displayed in the
setup (SATA HDD and SATA
CD-ROM). Other devices are
available in the OS after their
drivers are loaded.
SATA 4 and SATA 5 appear in
the HDD information listing.
Configure SATA as
RAID
Enabled
Disabled
SATA controller will be in RAID
mode and the Intel
®
RAID for
Serial ATA option ROM will
execute.
This item is unavailable when the
AHCI mode is enabled. This
mode can be selected only when
the SATA controller is in
Enhanced Mode.
When this mode is enabled, no
SATA drive information is
displayed.
Primary IDE Master <Not Installed/Drive
information>
Information only
Primary IDE Slave < Not Installed/Drive
information>
Information only
SATA Port 0 < Not Installed/Drive
information>
Information only. Unavailable
when the RAID Mode is enabled.
SATA Port 1 < Not Installed/Drive
information>
Information only. This field is
unavailable when the RAID Mode
is enabled.
SATA Port 2 < Not Installed/Drive
information>
Information only. This field is
unavailable when the RAID Mode
is enabled.
SATA Port 3 < Not Installed/Drive
information>
Information only. This field is
unavailable when the RAID Mode
is enabled.
SATA Port 4 < Not Installed/Drive
information>
Information only; This field is
only available when the AHCI
Mode is enabled.
SATA Port 5 < Not Installed/Drive
information>
Information only; This field is
only available when the AHCI
Mode is enabled.
