System BIOS Intel
®
Server Board S5400SF TPS
Revision 2.02
Intel order number: D92944-007
88
Setup Item Options Help Text Comments
Snoop Filter
Enabled
Disabled
The Snoop Filter component
monitors and controls the data
transactions between memory
and the processor(s).
FSB High Bandwidth
Optimization
Enabled
Disabled
[Enabled] – Optimize Front-Side
Bus for higher bandwidth when
1333 MHz FSB or faster
processor(s) are installed.
Note: Some applications benefit
from this option. [Enabled].
Information only. This option is set
to enabled always.
5.2.3.2.3 ATA Controller Screen
The ATA Controller screen provides fields to configure PATA and SATA hard disk drives. It also
provides information on the hard disk drives that are installed.
To access this screen from the Main screen, choose Advanced > ATA Controller.
Advanced
ATA Controller Configuration
Onboard PATA Controller Enabled/Disabled
Onboard SATA Controller Enabled/Disabled
SATA Mode Enhanced/Legacy
Legacy IDE Channel
SATA Only/Secondary SATA/Primary SATA/PATA Only
AHCI Mode Enabled/Disabled
Configure SATA as RAID Enabled/Disabled
► Primary IDE Master Not Installed/<Drive Info.>
► Primary IDE Slave Not Installed/<Drive Info.>
► SATA Port 0 Not Installed/<Drive Info.>
► SATA Port 1 Not Installed/<Drive Info.>
► SATA Port 2 Not Installed/<Drive Info.>
► SATA Port 3 Not Installed/<Drive Info.>
► SATA Port 4 Not Installed/<Drive Info.>
► SATA Port 5 Not Installed/<Drive Info.>
Figure 22. Setup Utility — ATA Controller Configuration Screen Display
