Intel
®
Server Board S5400SF TPS System BIOS
Revision 2.02
Intel order number: D92944-007
85
5.2.3.2.2 Memory Screen
The Memory screen allows the user to view details about the system memory FBDIMMs that
are installed. This screen also allows the user to open the Configure Memory RAS and
Performance screen.
To access this screen from the Main screen, choose Advanced > Memory.
Note: The following screenshot is for reference purposes only. The actual BIOS setup screen
accurately reflects the number of DIMM slots found on the server board.
Advanced
Memory Configuration
Total Memory <Total Physical Memory Installed in System>
Effective Memory <Total Effective Memory>
Current Configuration
<Maximum Performance Mode/Single-channel Mode/
Single-DIMM Sparing Mode/Dual-DIMM Sparing Mode>
Current Memory Speed <Speed that installed memory is running at.>
► Memory RAS and Performance Configuration
DIMM Information
DIMM_A1 Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_A2 Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_B1 Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_B2 Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_C1 Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_C2 Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_D1 Installed/Not Installed/Failed/Disabled/Spare Unit
DIMM_D2 Installed/Not Installed/Failed/Disabled/Spare Unit
Figure 20. Setup Utility — Memory Configuration Screen Display
