5.2.3.2.1.1 Processor # Information Screen
The Processor # Information screen provides a place for the user to view information about a
specific processor.
To access this screen from the Main screen, select Advanced > Processor > Processor #
Information, where # is the processor number you want to see.
Advanced
Processor <#> Information
Processor <#> Family
<String from Processor>
Maximum Frequency <Maximum Processor Speed Possible>
L2 Cache RAM <Size of the cache>
Processor Stepping <Stepping # of this processor>
CPUID Register <CPUID>
Figure 19. Setup Utility — Specific Processor Information Screen Display
Table 32. Setup Utility — Specific Processor Information Screen Fields
Setup Item Options Help Text Comments
Processor <#> Family Information only. Identifies the family or generation of the
processor.
Maximum Frequency Information only. Maximum frequency the processor core
supports.
L2 Cache RAM Information only. Size of the processor L2 cache.
Processor Stepping Information only. Stepping number of the processor.
CPUID Register Information only. CPUID register value identifies details
about the processor family, model, and stepping.
