Spares, parts list, and configuration guide

4
2. Spares and Accessories Order Codes
2.1 S1400FP Dedicated Spare and Accessories
Product Code
MM
UPC
EAN
Description
M
O
Q
BXSTS100C
900491
00735858205153
5032037009119
Box processor standard heat sink
1
AXXCA90X902UHS
919883
00735858242875
5032037037570
Passive Cu-Al heatsink optimized for S2400SC, S2400GP,
S1400FP in P4000 chassis
2
FFPUPSAD
921665
00735858247955
5032037042833
Accessory – dedicated air duct for S1400FP in P4000
Short chassis.
As accessory for KDK.
1
2.2 Compatible Riser Options
The risers below are compatible with Intel
®
Server Board S1400FP2 and S1400FP4 when used in PCIe slot 6
and in 3
rd
party rack chassis. Users may need to develop mounting mechanics to fit their own chassis.
Product Code
MM
UPC
Description
Image not yet available
AXX1UPCIEX16
919808
00735858244534
5032037039109
1
1U PCIe x16 riser, 1 slot, x16 electrical/x16 mechanical
