Spares, parts list, and configuration guide

1
1. System Product Order Codes
1.1 Product Descriptions – Overview
Product based on the Intel
®
Server Board S1400FP is offered as standard box board.
1.2 Available Board SKUs for S1400FP Family
Product Code
MM
UPC
EAN
Description
M
O
Q
DBS1400FP2
920570
00735858246668
5032037041126
Intel
®
Server Board S1400FP2
− 12’’ (W) x 9.5’’ (L)
− 6 UDIMM/RDIMM of DDR3/DDR3L
− Up to 8 SAS ports and 6 additional SATA
ports
− Dual GbE
− Compatible with Intel
®
Xeon
®
processor E5-
2400 family and Intel
®
Xeon
®
processor E5-
2400 v2 family.
− I/O shield
− 2 SATA cables
− Intel
®
Multi-Server Manager Software
− Quick Start Guide
5
DBS1400FP4
920571
00735858246675
5032037041133
Intel
®
Server Board S1400FP4
− 12’’ (W) x 9.5’’ (L)
− 6 U/R-DIMMs of DDR3/DDR3L
− Up to 8 SAS ports and 6 additional SATA
ports
− Quad GbE
− Compatible with Intel
®
Xeon
®
processor E5-
2400 family and Intel
®
Xeon
®
processor E5-
2400 v2 family.
− I/O shield
− 2 SATA cables
− Intel
®
Multi-Server Manager Software
− Quick Start Guide
5
