Spares, parts list, and configuration guide

7
Product Code
MM
UPC
EAN
MOQ
Description
Image not yet available
FUPSMSK
912773
00735858219518
5032037016292
1
Chassis Maintenance kit for P4000S server chassis
(Mechanical Spares Kit)
Includes mechanical parts – including:
 IO Bracket (without knockouts)
 IO Bracket (w/USB and D Sub knockout)
 Baseboard Insulators – uATX & ATX
 BBU Bracket
 Intrusion Switch Bracket
 CDROM Filler Panel
 ODD latch w/2 screws
 Rack Handles (set)
 Fan Holder Assembly
 CPU Ducts
 Air Dams
FUPSESK
912774
00735858219525
5032037016285
1
Chassis Maintenance kit for P4000S
(Electrical Spare Kit)
Includes:
 Front Panel Cable
 Dual USB Cable
 (4) SATA HDD Cables
 SATA ODD Cable
 SGPIO Cable
 I2C Cable
 SATA Power Adaptor Cable
Image not yet available
AXX2IOS
919757
735858239264
5032037034036
50
I/O Shield accessory for Intel
®
S2600CP2,
S2400GP2, S1400FP2 and S2400SC2 Server Boards
Image not yet available
AXX4IOS
919758
00735858238939
5032037033718
50
I/O Shield accessory for Intel
®
S2600CP4, S2600IP4,
S1400FP4 and S2400GP4 Server Boards
FUP4X35HSBP
913595
00735858220033
5032037019279
1
3.5" Hot Swap Backplane spare (for P4304 server
chassis)
Includes: 3.5" backplane board
Image not yet available
FUP8X35HSBP
916353
00735858222792
5032037033480
1
Hot Swap Back Plane spare for 8x3.5" Drive Cage Kit
FUP8X35HSDK for use with P4000 server chassis
Includes: (1) 3.5” backplane board
