6. Hard Disk Drives and Solid State Drives
The testing of hard disk drives and solid state drives was performed with the Intel
®
RAID
Controller RS25FB044 by Intel labs, independent test labs, or vendors. The compatibility and
stress testing is performed with the latest version of an operating system available at the time of
testing. Although a large sample of configurations was tested, not all devices were tested under
all operating systems, and not all possible combinations or configurations of third-party devices
were tested for inter-compatibility due to the large number of possible configurations. To verify
that the device is included for the server board as well as for the Intel
®
RAID Controller
RS25FB044, use the Server Configurator tool available at:
http://serverconfigurator.intel.com/default.aspx.
Note: All hard disk drives and solid state drives were not tested under all operating systems.
Any variations to the standard adapter installation process or to the expected adapter
functionality are documented in the Installation Guidelines section of this document. If there are
installation guidelines affecting a particular adapter and operating system combination, these
are referenced in the following table. If the installation guidelines are not noted in the following
table, then the adapter installed and functioned as expected, using the manufacturer’s
installation instructions or Intel’s best-known methods.
6.1 Hard Disk Drives and Solid State Drives (SSD)
Note: The hard disk drives and solid state drives are listed in the following table only if they
were attached to the Intel
®
RAID Controller RS25FB044 during testing.
Note: To select hard drives for Intel
®
Server Chassis and Intel
®
Server System, please use the
Server Configurator tool available at:
http://serverconfigurator.intel.com/default.aspx.
Solid State Drive List:
Manufactur
e
Type
Speed
Model
FW version
Capacity
Size
ADATA
SATA
3Gb/s
AS599S-128GM-C
3.1.0
128GB
2.5"
ADATA
SATA
3Gb/s
AS599S-256GM-C
3.1.0
256GB
2.5"
ANOBIT
SATA
3Gb/s
Genesis-1
2.21
200GB
3.5"
Intel
SATA
6Gb/s
S3700 series, SSDSC2BA800G3
0250
800GB
2.5"
Intel
SATA
6Gb/s
S3700 series, SSDSC2BA400G3
0250
400GB
2.5"
Intel
SATA
6Gb/s
S3700 series, SSDSC2BA200G3
0250
200GB
2.5"
Intel
SATA
6Gb/s
S3700 series, SSDSC2BA100G3
0250
100GB
2.5"
Intel
SATA
6Gb/s
520 series, SSDSC2BW060A3
400i
60GB
2.5"
Intel
SATA
6Gb/s
520 series, SSDSC2BW120A3
400i
120GB
2.5"
Intel
SATA
6Gb/s
520 series, SSDSC2BW180A3
400i
180GB
2.5"
Intel
SATA
6Gb/s
520 series, SSDSC2BW240A3
400i
240GB
2.5"
Intel
SATA
6Gb/s
520 series, SSDSC2BW480A3
400i
480GB
2.5"
Intel
SATA
6Gb/s
510 series, SSDSC2MH250A2xx
PWG4
250GB
2.5"
Intel
SATA
6Gb/s
510 series, SSDSC2MH120A2xx
PPG4
120GB
2.5"
Intel
SATA
3Gb/s
320 series, SSDSA2BW80G3
4PC10362
80GB
2.5"
Intel
SATA
3Gb/s
320 series, SSDSA2BW120G3
4PC10362
120GB
2.5"
Intel
SATA
3Gb/s
320 series, SSDSA2BW160G3
4PC10362
160GB
2.5"
Intel
SATA
3Gb/s
320 series, SSDSA2BW300G3
4PC10362
300GB
2.5"
