Intel RAID RS2 and RS25 Family Product lists and configuration guide

14
1.4
Intel
®
RAID Expander Order Codes
Product Code
MM
UPC
Description
Minimum
Order
Quantity
RES2CV360
918935
00735858241168
Intel
®
RAID Expander RES2CV360
6Gb/s SAS/SATA
4 ports in, 32 ports out or 8 ports in, 28 ports
out
Powered source: standard 4-pin connector
from power supply
No cables included
RES2CV360 Compatible Matrix
5
RES2CV240
918934
00735858241175
Intel
®
RAID Expander RES2CV240
6Gb/s SAS/SATA
4 ports in, 20 ports out or 8 ports in, 16 ports
out
Powered source: standard 4-pin connector
from power supply
No cables included
RES2CV240 Compatible Matrix
5
RES2SV240
908137
00735858216289
Intel
®
RAID Expander RES2SV240
6Gb/s SAS/SATA
4 ports in, 20 ports out or 8 ports in, 16 ports
out
MD2 Low Profile, half-length form factor
Powered source: either PCIe Slot or standard
4-pin connector from power supply
Six MS to MS cables included
RES2SV240 Compatible Matrix
5
RES2SV240NC
915431
00735858221375
Intel
®
RAID Expander RES2SV240
“NC” (RES2SV240 shipped without cables)
6Gb/s SAS/SATA
4 ports in, 20 ports out or 8 ports in, 16 ports
out
MD2 Low Profile, half-length form factor
Powered source: either PCIe Slot or standard
4-pin connector from power supply
No cables included
RES2SV240NC Compatible Matrix
5
