Hardware User Guide

Intel® Integrated RAID Module RMT3PB080 and RMT3CB080 Hardware User’s Guide 27
Table 5. Host Board Interface Connector Pin-Out
Pin # Description Pin # Description
1 RSVD_SE 2 GND
3 GND 4 PCIe Gen3 Rp [0]
5 PCIe Gen3 Tp [0] 6 PCIe Gen3 Rn [0]
7 PCIe Gen3 Tn [0] 8 GND
9 GND 10 PCIe Gen3 Rp [1]
11 PCIe Gen3 Tp [1] 12 PCIe Gen3 Rn [1]
13 PCIe Gen3 Tn [1] 14 GND
15 GND 16 PCIe Gen3 Rp [2]
17 PCIe Gen3 Tp [2] 18 PCIe Gen3 Rn [2]
19 PCIe Gen3 Tn [2] 20 GND
21 GND 22 PCIe Gen3 Rp [3]
23 PCIe Gen3 Tp [3] 24 PCIe Gen3 Rn [3]
25 PCIe Gen3 Tn [3] 26 GND
27 GND 28 PCIe Gen3 Rp [4]
29 PCIe Gen3 Tp [4] 30 PCIe Gen3 Rn [4]
31 PCIe Gen3 Tn [4] 32 GND
33 GND 34 PCIe Gen3 Rp [5]
35 PCIe Gen3 Tp [5] 36 PCIe Gen3 Rn [5]
37 PCIe Gen3 Tn [5] 38 GND
39 GND 40 PCIe Gen3 Rp [6]
41 PCIe Gen3 Tp [6] 42 PCIe Gen3 Rn [6]
43 PCIe Gen3 Tn [6] 44 GND
45 GND 46 PCIe Gen3 Rp [7]
47 PCIe Gen3 Tp [7] 48 PCIe Gen3 Rn [7]
49 PCIe Gen3 Tn [7]] 50 GND
51 GND 52 rSASm REFCLK- [0]
53 SMB DAT 54 rSASm REFCLK+ [0]
55 SMB CLK 56 GND
57 GND 58 PERST#
59 RSVD_DN 60 WAKE#
