Intel RAID RS2 and RS25 Family Product lists and configuration guide

18
NOTE: In the following
images, straight connectors
and right-angel connectors
are not clearly shown.
Product Code
MM
UPC
Description
Minimum
Order
Quantity
AXXCBL1030MR7R
921079
00735858245258
Each set provides two 1030mm cables with a
four port Mini-SAS 8087 connector on one
end and four 7-pin SATA style pins on the
other end. The 8-pin side-band SGPIO cable
with a “Y type” header (one with 4-pin and
one with 5-pin) is included.
1
Note: For more cabling information, refer to C200 C600 Enclosure Management Cabling Guide available
at http://www.intel.com/support
.
