Intel RAID RS2 and RS25 Family Product lists and configuration guide
Table Of Contents
11
Product Code
MM
UPC
Description
Minimum
Order
Quantity
RMS25CB040
924872
00735858238984
Intel
®
Integrated RAID Module RMS25CB040
LSI* SAS2208 ROC
6Gb/s SAS/SATA
x8 PCIe 3.0
4 internal ports
1GB embedded memory
Require one 80-pins on-board module connector
Support RAID 0,1,10,5,6,50,60
RAID Premium Feature Key supported
Cables are not included
RMS25CB040 Compatible Matrix
5
RMT3CB080
924873
00735858238991
Intel
®
Integrated RAID Module RMT3CB080
LSI* SAS2208 ROC
6Gb/s SAS/SATA
x8 PCIe 3.0
4 internal ports
512MB embedded memory
Require one 80-pins on-board module connector
Support RAID 0,1,10,5,6,50,60
RAID Premium Feature Key supported
Cables are not included
RMT3CB080 Compatible Matrix
5
RMS25KB080
917089
(being updated to
924454)
00735858244831
Intel
®
Integrated RAID Module RMS25KB080
LSI* SAS2308 Processor Chip
6Gb/s SAS/SATA
x8 PCIe 3.0 support with MM# 924454
8 internal ports
32KB Context, no BBU option
MD2 Low Profile, half-length form factor
Support RAID 0,1,10,1E
Cables are not included
RMS25KB080 Compatible Matrix
5
RMS25KB040
917090
(being updated to
924455)
00735858239035
Intel
®
Integrated RAID Module RMS25KB040
LSI* SAS2308 Processor Chip
6Gb/s SAS/SATA
x8 PCIe 3.0 support with MM# 924455
4 internal ports
32KB Context, no BBU option
MD2 Low Profile, half-length form factor
Support RAID 0,1,10,1E
Cables are not included
RMS25KB040 Compatible Matrix
5
