Intel RAID RS2 and RS25 Family Product lists and configuration guide
Table Of Contents
12
Product Code
MM
UPC
Description
Minimum
Order
Quantity
RMS25JB080
917087
(being updated to
924452)
00735858239004
Intel
®
Integrated RAID Module RMS25JB080
LSI* SAS2308 Processor Chip
6Gb/s SAS/SATA
x8 PCIe 3.0 support with MM# 924452
8 internal ports
32KB Context, no BBU option
Require one 80-pins on-board module connector
Support RAID 0,1,10,1E
Cables are not included
RMS25JB080 Compatible Matrix
5
RMS25JB040
917088
(being updated to
924453)
00735858239011
Intel
®
Integrated RAID Module RMS25JB040
LSI* SAS2308 Processor Chip
6Gb/s SAS/SATA
x8 PCIe 3.0 support with MM# 924453
4 internal ports
32KB Context, no BBU option
Require one 80-pins on-board module connector
Support RAID 0,1,10,1E
Cables are not included
RMS25JB040 Compatible Matrix
5
AXXRMS2MH080
907847
00735858215619
Intel
®
Integrated RAID Module RMS2MH080
LSI* SAS2108 ROC
6Gb/s SAS/SATA, x8 PCIe 2.0
8 internal ports
512MB embedded memory
Require two 50-pins on-board module connector
Support RAID 0,1,10,5,6,50,60
RAID Premium Feature Key supported
Two MS to 7pin SATA cables included
RMS2MH080 Compatible Matrix
5
AXXRMS2AF080
907853
00735858215732
Intel
®
Integrated RAID Module RMS2AF080
LSI* SAS2008 Processor Chip
6Gb/s SAS/SATA, x4 PCIe 2.0
8 internal ports
2MB Context, no BBU option
Require one 50-pins on-board module connector
Support RAID 0,1,10,5,50
Eight SATA cables included
RMS2AF080 Compatible Matrix
5
AXXRMS2AF040
907854
00735858215756
Intel
®
Integrated RAID Module RMS2AF040
LSI* SAS2008 Processor Chip
6Gb/s SAS/SATA, x4 PCIe 2.0
4 internal ports
2MB Context, no BBU option
Require one 50-pins on-board module connector
Support RAID 0,1,10,5,50
Four SATA cables included
RMS2AF040 Compatible Matrix
5
