Figure 30. Micro-FCBGA Package - Bottom View
1
2
3
4 6 8 10 12 14 16 18
20
22 24 26
5 7 9 11
13 15 17
19 21 23 25
A
B
C
E
D
F
G
H
J
K
L
M
N
P
R
T
U
V
W
Y
AA
AB
AC
AD
AE
AF
NOTE:
All dimensions in millimeters. Values shown are for reference only. See Table 37 for specific details.
25X 1.27
(e)
25X 1.27
(e)
1.625 (S)
4 places
1.625 (S)
4 places
