Electrical Specifications
32 Mobile Intel

Pentium

4 Processor-M Datasheet
NOTES:
1. Unless otherwise noted, all specifications in this table apply to all processor frequencies.
2. All outputs are open-drain.
3. V
IH
and V
OH
may experience excursions above V
CC
. However, input signal drivers must comply with the
signal quality specifications in Section 3.
4. The V
CC
referred to in these specifications refers to instantaneous V
CC
.
5. This specification applies to the asynchronous GTL+ signal group.
6. The maximum output current is based on maximum current handling capability of the buffer and is not
specified into the test load shown in
Figure 8.
7. Refer to the processor I/O Buffer Models for I/V characteristics.
8. Vol max of 0.270 Volts is guaranteed when driving into a test load of 50 Ω as indicated in Figure 8 for the
Asynchronous GTL+ signals.
9. Leakage to V
SS
with pin held at V
CC
.
10.Leakage to V
CC
with pin held at 300 mV.
Table 14. Asynchronous GTL+ Signal Group DC Specifications
Symbol Parameter Min Max Unit Notes
1
VIH
Input High Voltage
Asynch GTL+
1.10*GTLREF VCC
V 3, 4, 5
VIL
Input Low Voltage
Asynch. GTL+
0 0.9*GTLREF V 5
VOH Output High Voltage N/A V
CC
V 2, 3, 4
IOL Output Low Current N/A 50 mA 6, 8
I
HI
Pin Leakage High N/A 100 µA 9
I
LO
Pin Leakage Low N/A 500 µA 10
Ron
Buffer On Resistance
Asynch GTL+
7 11 Ω 5, 7
