Intel® Server System R2000LH2/T2 Product Family TPS Additonal System Boards
Revision 1.0
85
10.5.3
Motherboard Power Connectors
There are two power connectors (J8 and J6) connecting main power from the PDB to the
motherboard.
Main power to the server board power is supplied via two power connectors, connecting main
power from the PDB to the motherboard. Each connector is labeled as J8 and J6 on the PDB.
The following tables provide the pin-out for both connectors.
Table 37. Main Power (J8) Connector Pin-out
Pin #
Signal Description
Pin #
Signal Description
1
GROUND
9
P12V1/2
2
GROUND
10
P12V1/2
3
GROUND
11
P12V1/2
4
GROUND
12
P12V1/2
5
GROUND
13
P12V1/2
6
GROUND
14
P12V1/2
7
GROUND
15
P12V1/2
8
GROUND
16
P12V1/2
Table 38. Main Power (J6) Connector Pin-out
Pin #
Signal Description
Pin #
Signal Description
1
GROUND
9
P12V1/2
2
GROUND
10
P12V1/2
3
GROUND
11
P12V1/2
4
GROUND
12
P12V1/2
5
GROUND
13
P12V1/2
6
GROUND
14
P12V1/2
7
GROUND
15
P12V1/2
8
GROUND
16
P12V1/2
