Intel® Server System R2000LH2/T2 Product Family TPS Intel® Local Control Panel
Revision 1.0
71
Server Name: Value specified in the product name in the product FRU information in the
main board BMC FRU.
Server Model: Value specified in the product part number in the product FRU information
in the main board BMC FRU.
Asset tag: Value specified in the product asset tag in the product FRU information in the
main board BMC FRU.
Server GUID: System UUID stored by BIOS.
Custom String: Custom string placed by the OEM end user.
8.4.3
BMC IP Configuration
Selection of BMC IP Conf item in the View menu displays the RMM4 IP configuration details.
These details show whether the IP is configured using DHCP or Static, IP Address, Subnet
Mask, and Gateway.
Figure 55. LCP – BMC IP Configuration
8.4.4
RMM4 IP Configuration
Selection of RMM4 IP Conf item in the View menu displays the BMC IP configuration details.
These details show whether the IP is configured using DHCP or Static, IP Address, Subnet
Mask, and Gateway.
Figure 56. LCP – RMM4 IP Configuration
