Front Control Panel and I/O Panel Overview Intel® Server System R2000LH2/T2 Product Family TPS
Revision 1.0
64
off the system. The integrated LED is a single color (Green) and is capable of supporting
different indicator states as defined in the following table.
Table 32. Power/Sleep LED Functional States
State
Power Mode
LED
Description
Power-off
Non-ACPI
Off
System power is off, and the BIOS has not initialized the chipset.
Power-on
Non-ACPI
On
System power is on.
S5
ACPI
Off
Mechanical is off, and the operating system has not saved any
context to the hard disk.
S4
ACPI
Off
Mechanical is off. The operating system has saved context to the
hard disk.
S3-S1
ACPI
Slow blink
DC power is still on. The operating system has saved context
and gone into a level of low-power state.
S0
ACPI
Steady on
System and the operating system are up and running.
H – Drive Activity LED: The drive activity LED on the front panel indicates drive activity
from the on-board hard disk controllers. The server board also provides a header giving
access to this LED for add-in controllers.
