Front Control Panel and I/O Panel Overview Intel® Server System R2000LH2/T2 Product Family TPS
Revision 1.0
60
7. Front Control Panel and I/O Panel Overview
All system configurations include a Control Panel on the front of the system providing push
button system controls and LED indicators for several system features. This chapter describes
the features and functions of front panel options.
7.1
I/O Panel Features
Figure 45. Front I/O Panel Features
Label
Description
A
Asset Tag
B
Slimline Optical Drive Bay
C
Video Port
D
USB Ports
E
Front Control Panel
F
Hard Disk Drive Bays
