Storage Controller Options Overview Intel® Server System R2000LH2/T2 Product Family TPS
Revision 1.0
58
6.2
Embedded Software RAID Support
The system supports two embedded software RAID options:
Intel
®
Embedded Server RAID Technology 2 (ESRT2) based on LSI* MegaRAID SW
RAID technology
Intel
®
Rapid Storage Technology (RSTe)
Using the <F2> BIOS Setup Utility, accessed during system POST, options are available to
enable/disable SW RAID, and select which embedded software RAID option to use.
6.2.1
Intel
®
Embedded Server RAID Technology 2 (ESRT2)
Features of the embedded software RAID option Intel
®
Embedded Server RAID Technology 2
(ESRT2) include the following:
Based on LSI* MegaRAID Software Stack
Software RAID with system providing memory and CPU utilization
Supported RAID Levels – 0,1,5,10
- 4 & 8 Port SATA RAID 5 support provided with appropriate Intel
®
RAID C600
Upgrade Key
- 4 & 8 Port SAS RAID 5 support provided with appropriate Intel
®
RAID C600 Upgrade
Key
Maximum drive support = 8
Open Source Compliance = Binary Driver (includes Partial Source files) or Open Source
using MDRAID layer in Linux
OS Support = Windows 7*, Windows 2008*, Windows 2003*, RHEL*, SLES, other Linux
variants using partial source builds
Utilities = Windows* GUI and CLI, Linux GUI and CLI, DOS CLI, and EFI CLI
6.2.2
Intel
®
Rapid Storage Technology (RSTe)
Features of the embedded software RAID option Intel
®
Rapid Storage Technology (RSTe)
include the following:
Software RAID with system providing memory and CPU utilization
Supported RAID Levels – 0,1,5,10
- 4 Port SATA RAID 5 available standard (no option key required)
- 8 Port SATA RAID 5 support provided with appropriate Intel
®
RAID C600 Upgrade
Key
- No SAS RAID 5 support
Maximum drive support = 32 (in arrays with 8 port SAS), 16 (in arrays with 4 port SAS),
128 (JBOD)
Open Source Compliance = Yes (uses MDRAID)
