Intel® Server System R2000LH2/T2 Product Family TPS Power Subsystem
Revision 1.0
25
Table 15. Over Voltage Protection (OVP) Limits
Output Voltage
Min (V)
Max (V)
+12V
13.3
14.5
12VSB
13.3
14.5
3.5.18
Over-temperature Protection (OTP)
The power supply is protected against over temperature conditions caused by loss of fan
cooling or excessive ambient temperature. In an OTP condition the PSU will shut down. When
the power supply temperature drops to within specified limits, the power supply will restore
power automatically, while the 12VSB remains always on. The OTP circuit has built-in margin
so that the power supply will not oscillate on and off due to temperature recovering condition.
The OTP trip level has a minimum of 4°C of ambient temperature margin.
