Intel® Server System R2000LH2/T2 Product Family TPS Power Subsystem
Revision 1.0
19
3.3
Power Supply Module Efficiency
The following table provides the required minimum efficiency level at various loading conditions.
These are provided at three different load levels: 100%, 50%, and 20%. Efficiency is tested over
an AC input voltage range of 115 VAC to 220 VAC.
Table 6. 1600 Watt (AC) Power Supply Efficiency (Gold)
Loading
100% of
maximum
50% of
maximum
20% of
maximum
10% of
maximum
Minimum
Efficiency
91%
94%
90%
82%
