Technical Product Specification

Intel® Server System R2000LH2/T2 Product Family TPS Product Family Overview
Revision 1.0
5
Feature
Description
options
 Two 7-pin single port AHCI SATA connectors capable of supporting up to 6 GB/sec
 Two SCU 4-port mini-SAS connectors capable of supporting up to 3 GB/sec
SAS/SATA
 Intel
®
RAID C600 Upgrade Key support providing optional expanded SATA/SAS RAID
capabilities
Security
TPM Module AXXTPME5 (Accessory Option)
Server Management
 Integrated Baseboard Management Controller, IPMI 2.0 compliant
 Support for Intel
®
Server Management Software
 Intel
®
Remote Management Module 4 Lite – Accessory Option
 Intel
®
Remote Management Module 4 Management NIC – Accessory Option
Power Supply
Options
 The server system can have up to two power supply modules installed, providing
support for the following power configurations: 1+0, 1+1 Redundant Power, and 2+0
Combined Power
 Two power supply options:
 AC 1600W
 DC 1600W
Storage Bay Options

8x – 2.5” SATA/SAS Hot Swap Hard Drive Bays
 4x – 3.5” SATA/SAS Hot Swap Hard Drive Bays
 4x – 3.5” SATA/SAS Fixed Hard Drive Bays
Available Rack
Mount Kit Options
 Tool-less rack mount premium rail kit – Intel Product Code – AXXPRAIL
 Value rack mount rail kit – Intel Product Code – AXXVRAIL
 Cable Management Arm – Intel Product Code – AXX1U2UCMA (*supported with
AXXPRAIL only)
 2-post fixed mount bracket kit – Intel Product Code – AXX2POSTBRCKT
