Technical Product Specification

Product Family Overview Intel® Server System R2000LH2/T2 Product Family TPS
Revision 1.0
4
Note: Table 2
lists features common to both server product families. Features that are unique to
one product family are identified by either denoting the server system name or the integrated
server board name.
Table 1. Server System
Server System
Integrated Server Board
Intel
®
Server System R2000LH2
Intel
®
Server Board S4600LH2
Intel
®
Server System R2000LT2
Intel
®
Server Board S4600LT2
Table 2. System Feature Set
Feature
Description
Processor support
Support for up to four Intel
®
Xeon
®
processors E5-4600 product family with a Thermal
Design Power (TDP) of up to 130 W
Memory
 48 DIMM slots – 3 DIMMs / Channel – 4 memory channels per processor
 Unbuffered DDR3 (UDIMM), registered DDR3 (RDIMM), Load Reduced DDR3
(LRDIMM)
 Memory DDR3 data transfer rates of 800, 1066, 1333, and 1600 MT/s
 DDR3 standard I/O voltage of 1.5V and DDR3 Low Voltage of 1.35V
Chipset
Intel
®
C600-A chipset with support for optional Storage Option Select keys
External I/O
connections

DB-15 Video connector (Rear)
 RJ-45 Serial Port A connector
 S4600LH2 Dual-port Network Interface supporting 10/100/1000Mbps
 S4600LT2 Dual-port Network Interface supporting 100/1000/10000Mbps
 6 USB 2.0 connectors (4 rear + 2 front)
Internal I/O
connectors / headers
 One 2x5 pin connector providing front panel support for two USB ports
 One Type-A USB 2.0 connector
 One 2x15 pin SSI-EEB compliant front panel header
 One 2x7pin Front Panel Video connector
 One DH-10 Serial Port B connector
Optional I/O Module
support
The following I/O modules utilize a single proprietary on-board connector. An installed I/O
module can be supported in addition to standard on-board features and any add-in
expansion cards.
 Quad port 1 GbE based on Intel
®
Ethernet Controller I350 – RMS25CB0080
 Dual port 10GBase-T Ethernet module based on Intel
®
Ethernet Controller I350
 Dual SFP+ port 10GbE module based on Intel
®
82500 10 GbE controller
 Single Port FDR speed Infiniband* module with QSFP connector
System Fans
11 managed system fan headers
Riser Cards
Two riser card slots:
 Each riser card slot has a total of 48 PCIe lanes routed to them.
 Each riser card slot supports various Full Height Full Length (FHFL) and Full Height
Half Length (FHHL) cards.
Video

Integrated 2D Video Controller
 16 MB DDR3 Memory
On-board storage
controllers and
 One eUSB 2x5 pin connector to support 2mm low-profile eUSB solid state devices
