Technical Product Specification

Intel® Server System R2000LH2/T2 Product Family TPS Introduction
Revision 1.0
1
1. Introduction
This Technical Product Specification (TPS) provides system level information for the Intel
®
Server System R2000LH2 and Intel
®
Server System R2000LT2 product families. The system
level features of both these product families are common, however the server board integrated
into them is different. The Intel
®
Server System R2000LH2 product family is integrated with an
Intel
®
Server Board S4600LH2 and the Intel
®
Server System R2000LTH2 product family is
integrated with the Intel
®
Server Board S4600LT2.
This document describes the functions and features of the integrated server system which
includes the chassis layout, system boards, power subsystem, cooling subsystem, storage
subsystem options, and available installable options. Server board specific details can be
obtained by referencing the Intel
®
Server Boards S4600LH2/T2 Product Specification.
In addition, design-level information related to specific server board components or subsystems
can be obtained by ordering External Product Specifications (EPS) or External Design
Specifications (EDS) related to this server generation. EPS and EDS documents are made
available under NDA with Intel and must be ordered through your local Intel representative. See
the Reference Documents
section for a complete list of available documents.
1.1
Chapter Outline
This document is divided into the following chapters:
 Chapter 1 – Introduction
 Chapter 2 – Product Family Overview
 Chapter 3 – Power Subsystem
 Chapter 4 – Thermal Management
 Chapter 5 – System Storage and Peripherals Drive Bay Overview
 Chapter 6 – Storage Controller Options Overview
 Chapter 7 – Front Control Panel and I/O Panel Overview
 Chapter 8 – Intel
®
Local Control Panel
 Chapter 9 – PCI Riser Card Support
 Chapter 10 – Additional System Boards
 Chapter 11 – Front Panel
 Chapter 12 – IO Module Support
 Chapter 13 –Intel
®
Intelligent Power Node Manager (NM)
 Appendix A – Integration and Usage Tips
 Appendix B – POST Code Diagnostic LED Decoder
 Appendix C – Post Code Errors
 Glossary
 Reference Documents
