Intel® Server System R2000LH2/T2 Product Family TPS Appendix C: POST Code Errors
Revision 1.0
109
Error Code
Error Message
Response
85E5
DIMM_N2 encountered a Serial Presence Detection (SPD) failure
Major
85E6
DIMM_N3 encountered a Serial Presence Detection (SPD) failure
Major
85E7
DIMM_P1 encountered a Serial Presence Detection (SPD) failure
Major
85E8
DIMM_P2 encountered a Serial Presence Detection (SPD) failure
Major
85E9
DIMM_P3 encountered a Serial Presence Detection (SPD) failure
Major
85EA
DIMM_R1 encountered a Serial Presence Detection (SPD) failure
Major
85EB
DIMM_R2 encountered a Serial Presence Detection (SPD) failure
Major
85EC
DIMM_R3 encountered a Serial Presence Detection (SPD) failure
Major
85ED
DIMM_T1 encountered a Serial Presence Detection (SPD) failure
Major
85EE
DIMM_T2 encountered a Serial Presence Detection (SPD) failure
Major
85EF
DIMM_T3 encountered a Serial Presence Detection (SPD) failure
Major
8604
POST Reclaim of non-critical NVRAM variables
Minor
8605
BIOS Settings are corrupted
Major
8606
NVRAM variable space was corrupted and has been reinitialized
Major
92A3
Serial port component was not detected
Major
92A9
Serial port component encountered a resource conflict error
Major
A000
TPM device not detected.
Minor
A001
TPM device missing or not responding.
Minor
A002
TPM device failure.
Minor
A003
TPM device failed self-test.
Minor
A100
BIOS ACM Error
Major
A421
PCI component encountered a SERR error
Fatal
A5A0
PCI Express component encountered a PERR error
Minor
A5A1
PCI Express component encountered an SERR error
Fatal
A6A0
DXE Boot Service driver: Not enough memory available to shadow a Legacy
Option ROM
Minor
