Appendix C: POST Code Errors Intel® Server System R2000LH2/T2 Product Family TPS
Revision 1.0
108
Error Code
Error Message
Response
853E
DIMM_L1 failed test/initialization
Major
853F
DIMM_L2 failed test/initialization
Major
85C0
DIMM_L3 failed test/initialization
Major
85C1
DIMM_M1 failed test/initialization
Major
85C2
DIMM_M2 failed test/initialization
Major
85C3
DIMM_M3 failed test/initialization
Major
85C4
DIMM_N1 failed test/initialization
Major
85C5
DIMM_N2 failed test/initialization
Major
85C6
DIMM_N3 failed test/initialization
Major
85C7
DIMM_P1 failed test/initialization
Major
85C8
DIMM_P2 failed test/initialization
Major
85C9
DIMM_P3 failed test/initialization
Major
85CA
DIMM_R1 failed test/initialization
Major
85CB
DIMM_R2 failed test/initialization
Major
85CC
DIMM_R3 failed test/initialization
Major
85CD
DIMM_T1 failed test/initialization
Major
85CE
DIMM_T2 failed test/initialization
Major
85CF
DIMM_T3 failed test/initialization
Major
855D
DIMM_K3 disabled
Major
855E
DIMM_L1 disabled
Major
855F
DIMM_L2 disabled
Major
85D0
DIMM_L3 disabled
Major
85D1
DIMM_M1 disabled
Major
85D2
DIMM_M2 disabled
Major
85D3
DIMM_M3 disabled
Major
85D4
DIMM_N1 disabled
Major
85D5
DIMM_N2 disabled
Major
85D6
DIMM_N3 disabled
Major
85D7
DIMM_P1 disabled
Major
85D8
DIMM_P2 disabled
Major
85D9
DIMM_P3 disabled
Major
85DA
DIMM_R1 disabled
Major
85DB
DIMM_R2 disabled
Major
85DC
DIMM_R3 disabled
Major
85DD
DIMM_T1 disabled
Major
85DE
DIMM_T2 disabled
Major
85DD
DIMM_T3 disabled
Major
857D
DIMM_K3 encountered a Serial Presence Detection (SPD) failure
Major
857E
DIMM_L1 encountered a Serial Presence Detection (SPD) failure
Major
857F
DIMM_L2 encountered a Serial Presence Detection (SPD) failure
Major
85E0
DIMM_L3 encountered a Serial Presence Detection (SPD) failure
Major
85E1
DIMM_M1 encountered a Serial Presence Detection (SPD) failure
Major
85E2
DIMM_M2 encountered a Serial Presence Detection (SPD) failure
Major
85E3
DIMM_M3 encountered a Serial Presence Detection (SPD) failure
Major
85E4
DIMM_N1 encountered a Serial Presence Detection (SPD) failure
Major
