The system BIOS has logic to cope with the random factor in correctable ECC errors. Rather than reporting
every correctable error that occurs, the BIOS has a threshold and only logs a correctable error when a
threshold value is reached. Additional correctable errors that occur after the threshold has been reached are
disregarded. In addition, on the expectation the server system may have extremely long operational runs
without being rebooted, there is a “Leaky Bucket” algorithm incorporated into the correctable error counting
and comparing mechanism. The “Leaky Bucket” algorithm reduces the correctable error count as a function of
time – as the system remains running for a certain amount of time, the correctable error count will “leak out” of
the counting registers. This prevents correctable error counts from building up over an extended runtime.
The correctable memory error threshold value is a configurable option in the <F2> BIOS Setup Utility, where
you can configure it for 20/10/5/ALL/None
Once a correctable memory error threshold is reached, the event is logged to the System Event Log (SEL) and
the appropriate memory slot fault LED is lit to indicate on which DIMM the correctable error threshold crossing
occurred.
3.2.4.5.2.2 Uncorrectable Memory ECC Error Handling
All multi-bit “detectable but not correctable“ memory errors are classified as Uncorrectable Memory ECC Errors.
This is generally a fatal error.
However, before returning control to the OS drivers from Machine Check Exception (MCE) or Non-Maskable
Interrupt (NMI), the Uncorrectable Memory ECC Error is logged to the SEL, the appropriate memory slot fault
LED is lit, and the System Status LED state is changed to a solid Amber.
3.2.4.5.3
Demand Scrubbing for ECC Memory
Demand scrubbing is the ability to write corrected data back to the memory once a correctable error is
detected on a read transaction. This allows for correction of data in memory at detect, and decrease the
chances of a second error on the same address accumulating to cause a multi-bit error (MBE) condition.
Demand Scrubbing is enabled/disabled (default is enabled) in the Memory Configuration screen in Setup.
3.2.4.5.4
Patrol Scrubbing for ECC Memory
Patrol scrubs are intended to ensure that data with a correctable error does not remain in DRAM long enough
to stand a significant chance of further corruption to an uncorrectable stage.
3.2.4.5.5
Rank Sparing Mode
Rank Sparing Mode enhances the system’s RAS capability by “swapping out” failing ranks of DIMMs. Rank
Sparing is strictly channel and rank oriented. Each memory channel is a Sparing Domain.
For Rank Sparing to be available as a RAS option, there must be 2 or more single rank or dual rank DIMMs, or
at least one quad rank DIMM installed on each memory channel.
Rank Sparing Mode is enabled/disabled in the Memory RAS and Performance Configuration screen in the <F2>
Bios Setup Utility
When Sparing Mode is operational, for each channel, the largest size memory rank is reserved as a “spare”
and is not used during normal operations. The impact on Effective Memory Size is to subtract the sum of the
reserved ranks from the total amount of installed memory.
Hardware registers count the number of Correctable ECC Errors for each rank of memory on each channel
during operations and compare the count against a Correctable Error Threshold. When the correctable error
count for a given rank hits the threshold value, that rank is deemed to be “failing”, and it triggers a Sparing Fail
Over (SFO) event for the channel in which that rank resides. The data in the failing rank is copied to the Spare
Rank for that channel, and the Spare Rank replaces the failing rank in the IMC’s address translation registers.
