S2600GZ and S2600GL

Appendix F: Supported Intel® Server Systems Intel® Server Board S2600GZ/GL TPS
Table 72. Intel
®
Server System R2000GZ/GL Product Family Feature Set
Feature
Description
Processor Support
 Support for one or two processors:
o Intel
®
Xeon
®
processor E5-2600 product family with TDP support up to 135 W
1,2
o Intel
®
Xeon
®
processor E5-2600 v2 product family with TDP support up to 130 W
Memory
 S2600GL - 16 DIMM slots – 2 DIMMs/Channel – 4 memory channels per processor
 S2600GZ - 24 DIMM slots – 3 DIMMs/Channel – 4 memory channels per processor
 Unbuffered DDR3 (UDIMM), Registered DDR3 (RDIMM), and Load Reduced DDR3
(LRDIMM)
 Memory DDR3 data transfer rates of 800, 1066, 1333 MT/s,1600 and 1866
3
MT/s
 DDR3 standard I/O voltage of 1.5V and DDR3 Low Voltage of 1.35V
Chipset
Intel
®
C602 chipset with support for optional Storage Option Select keys
External I/O
connections
 Video – Back Panel + Front Panel on Non-Max Hard drive SKUs
 RJ-45 Serial- A Port
 Four RJ-45 Network Interface Connectors supporting 10/100/1000Mb
 USB 2.0 connectors - 3 on back panel + 2 on front panel on non-max hard drive SKUs
Internal I/O
connectors/headers
 One Type-A USB 2.0 connector
 One DH-10 Serial-B port connector
Optional I/O Module
support
The following I/O modules utilize a single proprietary on-board connector. An installed I/O
module can be supported in addition to standard on-board features and any add-in expansion
cards.
 AXX4P1GBPWLIOM – Quad port 1 GbE based on Intel® Ethernet Controller I350
 AXX10GBTWLIOM – Dual RJ-45 port 10GBase-T I/O Module based on Intel® Ethernet
Controller x540
 AXX10GBNIAIOM – Dual SFP+ port 10GbE module based on Intel® 82599 10 GbE
controller
 AXX1FDRIBIOM – Single Port FDR 56GT/S speed InfiniBand module with QSFP
connector
 AXX2FDRIBIOM – Dual port FDR 56GT/S speed infiniband module with QSFP connector
 AXXQAAIOMOD - Intel
®
Quick Assist Accelerator Card
System Fans
 Five managed system fans
 One power supply fan for each installed power supply module
Riser Cards
Support for two riser card slots. Each riser card slot has support for the following riser card
options:
 3-slot PCIe Riser Card: (Slots 1 & 2) – PCIe x16 slot, x8 lanes, (Slot 3) – PCIe x8 slot, x8
lanes
 2-slot PCIe Riser Card: (Slot 1) – PCIe x16 slot, x16 lanes, (Slot 2) – PCIe x8 slot, x8
lanes
 3-slot PCIx/PCIe Riser Card: (Slots 1 & 2) – PCIx 64-bit, (Slot 3) – PCIe x8 slot, x8 lanes
Video
 Integrated 2D Video Controller
 16 MB DDR3 Memory
On-board storage
controllers and
options
 One eUSB 2x5 pin connector to support 2mm low-profile eUSB solid state devices
 Two 7-pin single port AHCI SATA connectors capable of supporting up to 6 GB/sec
 Two SCU 4-port mini-SAS connectors capable of supporting up to 3 GB/sec SAS/SATA
 Intel
®
Integrated RAID module support (Optional)
 Intel
®
RAID C600 Upgrade Key support providing optional expanded SATA/SAS RAID
capabilities
Security
Intel
®
Trusted Platform Module (TPM) - AXXTPME5 (Accessory Option)
Revision 2.4
226
