S2600GZ and S2600GL

Appendix B: Integrated BMC Sensor Tables Intel® Server Board S2600GZ/GL TPS
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event/Readi
ng Type
Event Offset Triggers
Contrib. To
System Status
Assert/
De-
assert
Readable
Value/Of
fsets
Event
Data
Rearm
Stand-
by
IO Module Temperature
(I/O Mod Temp)
26h
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
PCI Riser 1 Temperature
(PCI Riser 1 Temp)
27h
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
IO Riser Temperature
(IO Riser Temp)
28h
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Hot-swap Backplane 1
Temperature
(HSBP 1 Temp)
29h
Chassis-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Hot-swap Backplane 2
Temperature
(HSBP 2 Temp)
2Ah
Chassis-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Hot-swap Backplane 3
Temperature
(HSBP 3 Temp)
2Bh
Chassis-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
PCI Riser 2 Temperature
(PCI Riser 2 Temp)
2Ch
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
SAS Module Temperature
(SAS Mod Temp)
2Dh
Platform-
specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Exit Air Temperature
(Exit Air Temp)
2Eh
Chassis &
Platform
Specific
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Network Interface Controller
Temperature
(LAN NIC Temp)
2Fh All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
