S2600GZ and S2600GL

Intel® Server Board S2600GZ/GL TPS BIOS Setup Utility
6. TPM State
Option Values: <Displays current TPM Device State>
May be:
Enabled & Activated
Enabled & Deactivated
Disabled & Activated
Disabled & Deactivated
Help Text: <None>
Comments: Information only. Shows the current TPM device state.
A Disabled TPM device does not execute commands that use the TPM functions and TPM
security operations are not available.
An Enabled & Deactivated TPM is in the same state as a disabled TPM, except that setting of
the TPM ownership is allowed if it is not present already.
An Enabled & Activated TPM executes all commands that use the TPM functions and TPM
security operations are also available.
Note: This option appears only on boards equipped with a TPM.
Back to [Security Screen
]
7. TPM Administrative Control
Option Values: No Operation
Turn On
Turn Off
Clear Ownership
Help Text:
[No Operation] - No changes to current state.
[Turn On] - Enables and activates TPM.
[Turn Off] - Disables and deactivates TPM.
[Clear Ownership] - Removes TPM ownership & returns TPM to factory default state.
Note: Setting returns to [No Operation] on every boot.
Comments: Any Administrative Control operation selected will require the system to perform
a Hard Reset in order to become effective.
Note: This option appears only on boards equipped with a TPM.
Back to [Security Screen
]
12.2.4
Server Management Screen (Tab)
The Server Management screen allows the user to configure several server management features. This screen
also provides an access point to the screens for configuring Console Redirection, displaying system
information, and controlling the BMC LAN configuration.
To access this screen from the Main screen or other top-level “Tab” screen, press the right or left arrow keys to
traverse the tabs at the top of the Setup screen until the Server Management screen is selected.
Revision 2.4
157
