S2600GZ and S2600GL

Appendix B: Integrated BMC Sensor Tables Intel® Server Board S2600GZ/GL TPS
Full Sensor Name
(Sensor name in SDR)
Sensor
#
Platform
Applicability
Sensor Type
Event/Readi
ng Type
Event Offset Triggers
Contrib. To
System Status
Assert/
De-
assert
Readable
Value/Of
fsets
Event
Data
Rearm
Stand-
by
Power Supply 1 Temperature
(PS1 Temperature)
5Ch
Chassis-
specific
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Power Supply 2 Temperature
(PS2 Temperature)
5Dh
Chassis-
specific
Temperature
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog R, T A X
Hard Disk Drive 16 - 24
Status
(HDD 16 - 24 Status)
60h
–
68h
Chassis-
specific
Drive Slot
0Dh
Sensor
Specific
6Fh
00 - Drive Presence OK
As
and
De
– Trig Offset A X
01- Drive Fault Degraded
07 - Rebuild/Remap in
progress
Degraded
Processor 1 Status
(P1 Status)
70h All
Processor
07h
Sensor
Specific
6Fh
01 - Thermal trip Fatal
As
and
De
– Trig Offset M X
07 - Presence OK
Processor 2 Status
(P2 Status)
71h All
Processor
07h
Sensor
Specific
6Fh
01 - Thermal trip
Fatal
As
and
De
– Trig Offset M X
07 - Presence OK
Processor 1 Thermal Margin
(P1 Therm Margin)
74h All
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor 2 Thermal Margin
(P2 Therm Margin)
75h All
Temperature
01h
Threshold
01h
- - - Analog R, T A –
Processor 1 Thermal
Control %
(P1 Therm Ctrl %)
78h All
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog Trig Offset A –
Processor 2 Thermal
Control %
(P2 Therm Ctrl %)
79h All
Temperature
01h
Threshold
01h
[u] [c,nc]
nc =
Degraded
c = Non-fatal
As
and
De
Analog Trig Offset A –
Revision 2.4
204
