Intel® Pentium® 4 LGA775 / mPGA478 AMD K8(939/754) / K7 Installation Guide GH-PDU21-MF REV.
English Table of Content Checklist............................................................................................................3 Specification.......................................................................................................4 Feature..............................................................................................................4 Warranty Item.....................................................................................................5 Precautions...
English Checklist (1)GH-PDU21 -MF Cooler (2)LGA775 RM (3) P4 clips (8) Fan control box (9) Speed control & 3.5” bracket (4) K8 clip (5) K7 clip (10)Powercable (11) PCI bracket (6) Heat sink paste (7) Screw (12)GH-PDU21-MF (13) Double-sided adhesive strip user's manual (note1) The double-sided adhesive strip is to attach the fan control box to the chassis.
English Specification y y y y y y y Heat Sink Dimension : 110x110 x 109mm Heatpipe Number : 4 Fan Speed : 1,700~3,200 rpm Rated Voltage : 12V Noise :21.3 ~ 40.1 dBA Bearing Type: Ball Bearing Base Maerial : Copper w/ Ni coating y y y y y y Feature Fin Material : Al fin Rated Current : 0.1 ~ 0.5A Airflow : 36.2 ~ 68.5 CFM Life Expectancy : 50,000 hr Total Weight : 430g Application : Intel® Pentium® 4 LGA775 840 / 670 / 570(3.8GHz) Intel® Pentium® 4 478 3.
English Precautions The cooler fan speed levels provided are for reference use only. Please refer to the motherboard BIOS to verify actual fan speed levels. Each connector on the fan control box is foolproof. Read the user’s manual before use. Before use, please remove the bottom protective layer of the cooler. Please make sure the computer is turned off and its power disconnected prior to installation.
English Installation Instructions for Fan Control Box & Power Cable Connector for 3.5 Fan Speed controller Fan Control Box Power Cable connector Power connector for Cooler or Connect the other end of the power cable to the 3-pin CPU fan header on the motherboard. GH-PDU21-MF Connect the other end of the power cable to the 4-pin CPU fan header on the motherboard.
English Power Installation and 3.5” Fan Speed Controller Installation Figure 1 Securely hold the 3.5” fan speed controller bracket in place with the screws provided(Figure 1-1). Figure 1-1 Figure 1-2 Figure 2-1 Figure 3-1 Figure 4-1 Figure 4-2 Figure 2 Connect the cable connector of the 3.5" fan speed controller to the fan control box (Figure 2-1). Figure 3 Connect the power cable connector of the cooler to the fan control box (Figure 3-1).
English Power Installation and PCI Fan Speed Controller Installation Figure 1-1 GH-PDU21-MF Figure 1-2 Figure 1 Disassemble the turn knob, bolt and fan speed controller from the 3.5” bracket and reassemble these parts onto a PCI bracket in sequence. Figure 2-1 Figure 2 Place the PCI bracket with the fan speed controller in the selected PCI slot. Use screws to secure the PCI bracket in place. Figure 3-1 Figure 3 Repeat the steps in “Power Installation and 3.
Side A ARM Side B CAM Figure 1 Plastic Washers Figure3- 1 Figure 2 Figure3-2 To install GH-PDU21-MF on LGA775 motherboard needs both LGA775 RM & P4 clips. Please add an adequate layer of heat sink paste on the surface of the CPU. Figure 1 Place the LGA775RM onto the LGA775 motherboard so that side A is parallel with ARM and side B is parallel with CAM. Figure 2 From the underside of the motherboard, use screws (4) and plastic washers (4) together to secure the LGA775RM into place..
English Installation Instructions for Intel® Pentium® 4 mPGA478 Clips Figure 1-2 Figure 1-1 C B A Figure 2 Figure 1 Please add an adequate layer of heat sink paste on the surface of the CPU(Figure1-1). Figure 1-2 showing the correct installation of the cooler atop the CPU. Figure 2 Clip introduction-Part A: Secured to the retention mechanism hook. Part B: Tightly contact the cooler bracket. Part C: Secured to the retention mechanism hook.
English Installation Instructions for AMD K8 (939 / 754) Clip Figure 1 Please add an adequate layer of heat sink paste on the surface of the CPU. Figure 1-1 Figure 1-2 Figure 2 Figure 2 Figure showing the correct installation of the cooler atop the CPU. Figure 3 Align the three insert spaces of the clip with the three juts on the CPU socket and then push firmly downwards to hold the clip in space.
English Installation Instructions for AMD K7 Clip Figure 1-1 Figure 1-2 Figure 1-3 Figure 1 Please add an adequate layer of heat sink paste on the surface of the CPU. Remove the bracket of the cooler along the direction of the arrow (Figure 1-2). The bracket should be removed as that shown in Figure 1-3. A Figure 2-1 B Figure 2-2 Figure 2 Place point A of the clip (Figure2-1)on point B at the bottom of the cooler(Figure2-2).As Figure 2-3.
Intel® Pentium® 4 LGA775 / mPGA478 AMD K8 (939 / 754) / K7 GH-PDU21-MF
.......................................................................................................15 .......................................................................................................16 .......................................................................................................16 .......................................................................................................17 ........................................................................................
(1) GH-PDU21-MF (2) LGA775 (3) P4 (4) K8 (5) K7 (8) (9) 3.
y y y y y y y y : 110 x 110 x 109 mm :4 : 1,700 ~ 3,200 rpm : 12V : 21.3 ~40.1 dBA : Ball Bearing : : Aluminum P4 LGA775 y y y y y y y y y y y y y : 0.1~ 0.5 : 36.2 ~ 68.5 CFM : 50,000 hr : 430g : Intel® Pentium® 4 LGA775 840 / 670 / 570(3.8GHz) Intel® Pentium® 4 478 3.4GHz AMD AthlonTM FX55 / AMD AthlonTM XP 4000+ AMD K7 3200+ P4 mPGA478 4 (1,700~3,200 rpm) 3.
B I O S - 17 - GH-PDU21-MF
3.
3.5 1 3.5 1-2) ( 1-1 1-2 2 3.
PCI 1 3.5 ( ( 1-1 1-1) 1-2) PCI 1-2 2 PCI 2-1 PCI ( 3 3.
P4 LGA775 GH-PDU21-MF LGA775 & P4 LGA775 A B CPU 1 LGA775 A LGA775 LGA775 ( 2 1) 2) LGA775 ( 3-1) 3.
Intel® Pentium® 4 mPGA478 1 CPU CPU ( ( 1-1) 1-2) 1-2 1-1 C 2 B A B C A 2 : : : 3 (A B C C 3-2 3-1 4 3.
AMD K8 (939 / 754) 1 CPU ( 1-1 1-2) 1-2 2 CPU 2 3 CPU 3 4 CPU 3.
AMD K7 1 ( 1-2 1-1 A 1-3 1-3 B 2 A 2-1 2-2 CPU 1-2) 2-3 ( 2-2) ( 2-1) 2-3 B 3 CPU A 3 ( 2-1) B 4 ( 4 GH-PDU21-MF - 24 - 2-1~ 3.
