Intel NUC Board NUC5i5RYB and Intel NUC Board NUC5i3RYB Technical Product Specification
14
Table 2 lists the components identified in Figure 1.
Table 2. Components Shown in Figure 1
Item from Figure 1 Description
A Thermal solution
B Battery
C Processor fan header
D Onboard power button
E Power LED (Dual Color)
F Hard Disk Drive LED
G Standby Power LED
