Guidelines

Dual-Core Intel
®
Xeon
®
Processor 7000 Sequence Thermal /Mechanical Guidelines 7
1 Introduction
1.1 Objective
The purpose of this guide is to describe the reference thermal solution and design parameters
required for the Dual-Core Intel® Xeon® processor 7000 sequence. It is also the intent of this
document to comprehend and demonstrate the processor cooling solution features and
requirements. Furthermore, this document provides an understanding of the processor thermal
characteristics, and discusses guidelines for meeting the thermal requirements imposed on the
entire life of the processor. The thermal/mechanical solutions described in this document are
intended to aid component and system designers in the development and evaluation of processor
compatible solutions.
1.2 Scope
The thermal/mechanical solutions described in this document pertain only to a solution(s) intended
for use with the Dual-Core Intel Xeon processor 7000 sequence in 2U+ form factor systems. This
document contains the mechanical and thermal requirements of the processor cooling solution. In
case of conflict, the data in the Dual-Core Intel® Xeon® Processor 7000 Sequence Datasheet
supersedes any data in this document. Additional information is provided as a reference in the
appendix section(s).
1.3 References
Material and concepts available in the following documents may be beneficial when reading this
document.
Table 1-1. References (Sheet 1 of 2)
Document Comment
Dual-Core Intel® Xeon® Processor 7000 Sequence Datasheet http://developer.intel.com
mPGA604 Socket Design Guidlines http://developer.intel.com/
Dual-Core Intel® Xeon® Processor 2.80 GHz and Dual-Core Intel® Xeon®
Processor 7000 Sequence Cooling Solution Mechanical Models
See Table Note
Dual-Core Intel® Xeon® Processor 2.80 GHz and Dual-Core Intel® Xeon®
Processor 7000 Sequence Cooling Solution Thermal Models
See Table Note
Dual-Core Intel® Xeon® Processor 2.80 GHz and Dual-Core Intel® Xeon®
Processor 7000 Sequence Mechanical Models
See Table Note
Prescott, Nocona, and Potomac Processor BIOS Writer’s Guide See Table Note
IA-32 Intel® Architecture Software Developer’s Manual and Intel NetBurst®
Microarchitecture BIOS Writer’s Guide
See Table Note
Intel® Xeon™ Processor Family Thermal Test Vehicle User's Guide See Table Note
Chassis Strength and Stiffness Measurement and Improvement Guidelines for
Direct Chassis Attach Solutions
Currently Available
