Hardware Reference Manual 427
Intel
®
IXP2800 Network Processor
Performance Monitor Unit
33 DAP_DEQ_B3_DATA_RPH P_CLK single separate
Indicates pull data and command are being
dequeued from the data and command bank
FIFOs to the RMC (the command and data FIFOs
used in tandem for pulls to supply the address
and data respectively).
34 DAP_DEQ_B2_DATA_RPH P_CLK single separate
35 DAP_DEQ_B1_DATA_RPH P_CLK single separate
36 DAP_DEQ_B0_DATA_RPH P_CLK single separate
Indicates pull data and command are being
dequeued from the data and command bank
FIFOs to the RMC (the command and data FIFOs
used in tandem for pulls to supply the address
and data respectively).
37 csr_wr_data_avail P_CLK single separate
Indicates that CSR write data is ready to be
latched into the CSR.
38 bank3_enq_wph P_CLK single separate
Indicates pull data is being enqueued to a bank
FIFO in the pull bus interface block.
39 bank2_enq_wph P_CLK single separate
Indicates pull data is being enqueued to a bank
FIFO in the pull bus interface block.
40 bank1_enq_wph P_CLK single separate
Indicates pull data is being enqueued to a bank
FIFO in the pull bus interface block.
41 bank0_enq_wph P_CLK single separate
Indicates pull data is being enqueued to a bank
FIFO in the pull bus interface block.
42 reserved
43
DCB_BANK3_CMD_AVAL_
RDH
D_CLK single separate
Indicates that this bank FIFO has a command
available.
44
DCB_BANK2_CMD_AVAL_
RDH
D_CLK single separate
Indicates that this bank FIFO has a command
available.
45
DCB_BANK1_CMD_AVAL_
RDH
D_CLK single separate
Indicates that this bank FIFO has a command
available.
46
DCB_BANK0_CMD_AVAL_
RDH
D_CLK single separate
Indicates that this bank FIFO has a command
available.
47
DAP_CSR_READ_CMD_TA
KEN_WDH
D_CLK single separate
Indicates dequeueing of a CSR read command
and clears the CSR read request signal coming
out of d_command_bus_if.
48
DAP_BANK3_CMD_DEQ_
WDH
D_CLK single separate
Active to dequeue a DRAM command from bank
N's FIFO, generated by d_app block.
49
DAP_BANK2_CMD_DEQ_
WDH
D_CLK single separate
Active to dequeue a DRAM command from bank
N's FIFO, generated by d_app block.
50
DAP_BANK1_CMD_DEQ_
WDH
D_CLK single separate
Active to dequeue a DRAM command from bank
N's FIFO, generated by d_app block.
51
DAP_BANK0_CMD_DEQ_
WDH
D_CLK single separate
Active to dequeue a DRAM command from bank
N's FIFO, generated by d_app block.
52 split_cmd_wph P_CLK single separate
Active if the command will cross a 128-byte
boundary and thus be split across channels.
53 reserved
54 reserved
55 reserved
56 reserved
Table 184. IXP2800 Network Processor Dram CH2 PMU Event List (Sheet 3 of 5)
