Signal Group Type Signals
Test Point RSVD_TP
Other SKTOCC#,
PCI Express* Graphics
Differential PCI Express Input PEG_RXP[15:0], PEG_RXN[15:0]
Differential PCI Express Output PEG_TXP[15:0], PEG_TXN[15:0]
Single ended Analog Input PEG_RCOMP
Digital Media Interface (DMI)
Differential DMI Input DMI_RXP[3:0], DMI_RXN[3:0]
Differential DMI Output DMI_TXP[3:0], DMI_TXN[3:0]
Digital Display Interface
Differential DDI Output DDIB_TXP[3:0], DDIB_TXN[3:0], DDIC_TXP[3:0],
DDIC_TXN[3:0], DDID_TXP[3:0], DDID_TXN[3:0]
Intel
®
FDI
Single ended CMOS Input FDI_CSYNC
Single ended Asynchronous
CMOS Input
DISP_INT
Differential FDI Output FDI_TXP[1:0], FDI_TXN[1:0]
Notes: 1. See Signal Description on page 82 for signal description details.
2. SA and SB refer to DDR3/DDR3L Channel A and DDR3/DDR3L Channel B.
Test Access Port (TAP) Connection
Due to the voltage levels supported by other components in the Test Access Port
(TAP) logic, Intel recommends the processor be first in the TAP chain, followed by any
other components within the system. A translation buffer should be used to connect to
the rest of the chain unless one of the other components is capable of accepting an
input of the appropriate voltage. Two copies of each signal may be required with each
driving a different voltage level.
The processor supports Boundary Scan (JTAG) IEEE 1149.1-2001 and IEEE
1149.6-2003 standards. A few of the I/O pins may support only one of those
standards.
DC Specifications
The processor DC specifications in this section are defined at the processor pins,
unless noted otherwise. See Signal Description on page 82 for the processor pin
listings and signal definitions.
• The DC specifications for the DDR3/DDR3L signals are listed in the Voltage and
Current Specifications section.
• The Voltage and Current Specifications section lists the DC specifications for the
processor and are valid only while meeting specifications for junction temperature,
clock frequency, and input voltages. Read all notes associated with each
parameter.
7.6
7.7
