B
i
t
7
B
i
t
6
B
i
t
5
B
i
t
4
B
i
t
3
B
i
t
2
B
i
t
1
B
i
t
0
Hex V
CC
1 1 0 0 1 0 1 0 CAh 2.5100
1 1 0 0 1 0 1 1 CBh 2.5200
1 1 0 0 1 1 0 0 CCh 2.5300
1 1 0 0 1 1 0 1 CDh 2.5400
1 1 0 0 1 1 1 0 CEh 2.5500
1 1 0 0 1 1 1 1 CFh 2.5600
1 1 0 1 0 0 0 0 D0h 2.5700
1 1 0 1 0 0 0 1 D1h 2.5800
1 1 0 1 0 0 1 0 D2h 2.5900
1 1 0 1 0 0 1 1 D3h 2.6000
1 1 0 1 0 1 0 0 D4h 2.6100
1 1 0 1 0 1 0 1 D5h 2.6200
1 1 0 1 0 1 1 0 D6h 2.6300
1 1 0 1 0 1 1 1 D7h 2.6400
1 1 0 1 1 0 0 0 D8h 2.6500
1 1 0 1 1 0 0 1 D9h 2.6600
1 1 0 1 1 0 1 0 DAh 2.6700
1 1 0 1 1 0 1 1 DBh 2.6800
1 1 0 1 1 1 0 0 DCh 2.6900
1 1 0 1 1 1 0 1 DDh 2.7000
1 1 0 1 1 1 1 0 DEh 2.7100
1 1 0 1 1 1 1 1 DFh 2.7200
1 1 1 0 0 0 0 0 E0h 2.7300
1 1 1 0 0 0 0 1 E1h 2.7400
1 1 1 0 0 0 1 0 E2h 2.7500
1 1 1 0 0 0 1 1 E3h 2.7600
1 1 1 0 0 1 0 0 E4h 2.7700
1 1 1 0 0 1 0 1 E5h 2.7800
1 1 1 0 0 1 1 0 E6h 2.7900
1 1 1 0 0 1 1 1 E7h 2.8000
1 1 1 0 1 0 0 0 E8h 2.8100
1 1 1 0 1 0 0 1 E9h 2.8200
1 1 1 0 1 0 1 0 EAh 2.8300
1 1 1 0 1 0 1 1 EBh 2.8400
continued...
B
i
t
7
B
i
t
6
B
i
t
5
B
i
t
4
B
i
t
3
B
i
t
2
B
i
t
1
B
i
t
0
Hex V
CC
1 1 1 0 1 1 0 0 ECh 2.8500
1 1 1 0 1 1 0 1 EDh 2.8600
1 1 1 0 1 1 1 0 EEh 2.8700
1 1 1 0 1 1 1 1 EFh 2.8800
1 1 1 1 0 0 0 0 F0h 2.8900
1 1 1 1 0 0 0 1 F1h 2.9000
1 1 1 1 0 0 1 0 F2h 2.9100
1 1 1 1 0 0 1 1 F3h 2.9200
1 1 1 1 0 1 0 0 F4h 2.9300
1 1 1 1 0 1 0 1 F5h 2.9400
1 1 1 1 0 1 1 0 F6h 2.9500
1 1 1 1 0 1 1 1 F7h 2.9600
1 1 1 1 1 0 0 0 F8h 2.9700
1 1 1 1 1 0 0 1 F9h 2.9800
1 1 1 1 1 0 1 0 FAh 2.9900
1 1 1 1 1 0 1 1 FBh 3.0000
1 1 1 1 1 1 0 0 FCh 3.0100
1 1 1 1 1 1 0 1 FDh 3.0200
1 1 1 1 1 1 1 0 FEh 3.0300
1 1 1 1 1 1 1 1 FFh 3.0400
Processor—Electrical Specifications
Desktop 4th Generation Intel
®
Core
™
Processor Family, Desktop Intel
®
Pentium
®
Processor Family, and Desktop Intel
®
Celeron
®
Processor Family
Datasheet – Volume 1 of 2 December 2013
94 Order No.: 328897-004
