Signal Name Ball #
VCC A24
VCC A25
VCC A26
VCC A27
VCC A28
VCC A29
VCC A30
VCC B25
VCC B27
VCC B29
VCC B31
VCC B33
VCC B35
VCC C24
VCC C25
VCC C26
VCC C27
VCC C28
VCC C29
VCC C30
VCC C31
VCC C32
VCC C33
VCC C34
VCC C35
VCC D25
VCC D27
VCC D29
VCC D31
VCC D33
VCC D35
VCC E24
VCC E25
VCC E26
VCC E27
VCC E28
continued...
Signal Name Ball #
VCC E29
VCC E30
VCC E31
VCC E32
VCC E33
VCC E34
VCC E35
VCC F23
VCC F25
VCC F27
VCC F29
VCC F31
VCC F33
VCC F35
VCC G22
VCC G23
VCC G24
VCC G25
VCC G26
VCC G27
VCC G28
VCC G29
VCC G30
VCC G31
VCC G32
VCC G33
VCC G34
VCC G35
VCC H23
VCC H25
VCC H27
VCC H29
VCC H31
VCC H33
VCC H35
VCC J21
continued...
Signal Name Ball #
VCC J22
VCC J23
VCC J24
VCC J25
VCC J26
VCC J27
VCC J28
VCC J29
VCC J30
VCC J31
VCC J32
VCC J33
VCC J34
VCC J35
VCC K19
VCC K21
VCC K23
VCC K25
VCC K27
VCC K29
VCC K31
VCC K33
VCC K35
VCC L15
VCC L16
VCC L17
VCC L18
VCC L19
VCC L20
VCC L21
VCC L22
VCC L23
VCC L24
VCC L25
VCC L26
VCC L27
continued...
