Parameter Description Minimum Maximum Notes
RH
sustained storage
The maximum device storage relative
humidity for a sustained period of time.
60% @ 24 °C 5, 6
TIME
sustained storage
A prolonged or extended period of time;
typically associated with customer shelf
life.
0 Months 6 Months 6
Notes: 1. Refers to a component device that is not assembled in a board or socket that is not to be
electrically connected to a voltage reference or I/O signals.
2. Specified temperatures are based on data collected. Exceptions for surface mount reflow are
specified in by applicable JEDEC standard. Non-adherence may affect processor reliability.
3. T
ABSOLUTE
storage applies to the unassembled component only and does not apply to the shipping
media, moisture barrier bags, or desiccant.
4. Intel branded board products are certified to meet the following temperature and humidity limits
that are given as an example only (Non-Operating Temperature Limit: -40 °C to 70 °C,
Humidity: 50% to 90%, non-condensing with a maximum wet bulb of 28 °C). Post board attach
storage temperature limits are not specified for non-Intel branded boards.
5. The JEDEC, J-JSTD-020 moisture level rating and associated handling practices apply to all
moisture sensitive devices removed from the moisture barrier bag.
6. Nominal temperature and humidity conditions and durations are given and tested within the
constraints imposed by T
sustained storage
and customer shelf life in applicable Intel box and bags.
Package Mechanical Specifications—Processor
Desktop 4th Generation Intel
®
Core
™
Processor Family, Desktop Intel
®
Pentium
®
Processor Family, and Desktop Intel
®
Celeron
®
Processor Family
December 2013 Datasheet – Volume 1 of 2
Order No.: 328897-004 109
