Server Board Features
12 Intel Server Board SE7210TP1-E User Guide
Table 1 summarizes the major features of the server board.
Table 1. Server Board Features
Feature Description
Processors Support for an Intel
®
Pentium
®
4 processor in an mPGA478 package with a
800/533/400 MHz system bus
Memory
Four 184-pin DDR SDRAM Dual Inline Memory Module (DIMM) sockets
Support for up to 4 GB Unbuffered ECC system memory
Support for single-sided or double-sided DIMMs (DDR266/333/400)
- To run DDR400 memory at full speed requires an Intel Pentium 4 processor with
800 MHz system bus frequency.
- To run DDR333 memory at full speed requires an Intel Pentium 4 processor with
533 MHz system bus frequency. DDR333 memory will run at 320 MHz frequency
when using an Intel Pentium 4 processor with system bus frequency of 800 MHz.
- DDR266 memory may only be used with an Intel Pentium 4 processor with 400
MHz or 533 MHz system bus frequency.
Chipset Intel
®
827210 chipset, consisting of:
Intel
®
827210 Memory Controller Hub (MCH)
Intel
®
6300ESB I/O Controller Hub
Intel
®
82802AC 8 Megabit Firmware Hub (FWH)
I/O Control Winbond* W83627HF-AW LPC Bus I/O controller chip
Peripheral Interfaces
Three external USB 2.0 ports on the back panel with an additional internal
header, which provides support for one additional USB port for front panel
support (four total possible USB 2.0 ports)
One serial port and one serial header
Two IDE interfaces with Ultra 33, 66 and 100 DMA mode
Two Serial ATA connectors with support for RAID 0 and 1
One floppy drive interface with support for one drive
PS/2
*
keyboard and mouse ports
LAN
One Intel® 82547EI Platform LAN Connect (PLC) device for 10/100/1000
Mbits/second Ethernet LAN connectivity
One Intel® 82551QM device for 10/100 Mbits/second Ethernet LAN connectivity
Expansion
Capabilities
Two independent PCI buses (one 32-bit, 33 MHz, 5 V; one 64-bit, 66 MHz, 5V) with
four bus connectors:
Three PCI-X 64-bit PCI slots
One 32-bit PCI slot
Integrated Capabilities
Integrated 2D/3D graphics controller: ATI* Rage* XL Video Controller with 8 MB
of SDRAM
Single channel, Ultra 320 SCSI controller (only available on server board
SE7210TP1SCSI): Adaptec* AIC-7901
Fans Support for up to six system fans and one processor fan
BIOS Intel/AMI BIOS with support for:
Advanced Configuration and Power Interface (ACPI)
8 megabit symmetrical flash memory
Support for SMBIOS
continued
