75 F 001Fh Queue depth
76 F 470Eh Serial ATA capabilities
77 F 0006h Reserved for future Serial ATA definition
78 F 004Ch Serial ATA features supported
79 V 0040h Serial ATA features enabled
80 F 03FCh Major version number
81 F 0110h Minor version number
82 F 746Bh Command set supported
83 F 7469h Command sets supported
84 F 6163h Command set/feature supported extension
85 V 7469h Command set/feature enabled
86 V B449h Command set/feature enabled
87 V 6163h Command set/feature default
88 V 407Fh Ultra DMA Modes
89 F 0002h Time required for security erase unit completion
90 F 0001h Time required for enhanced security erase completion
91 V 00FEh Current advanced power management value
92 V FFFEh Master Password Revision Code
93 F 0h
Hardware reset result: the contents of bits (12:0) of this word shall
change only during the execution of a hardware reset
94 V 0h Vendor’s recommended and actual acoustic management value
95 F 0h Stream minimum request size
96 V 0h Streaming transfer time - DMA
97 V 0h Streaming access latency - DMA and PIO
98-99 F 0h Streaming performance granularity
100-103 V varies Maximum user LBA for 48-bit address feature set
104 V 0h Streaming transfer time - PIO
105 F 0001h Reserved
106 F 4000h Physical sector size / logical sector size
107 F 0h Inter-seek delay for ISO-7779 acoustic testing in microseconds
108-111 F varies Unique ID
112-115 F 0h Reserved for world wide name extension to 128 bits
116 V 0h Reserved for technical report
117-118 F 0h Words per logical sector
119 F 401Ch Supported settings
120 F 401Ch Command set/feature enabled/supported
121-126 F 0h Reserved
127 F 0h Removable Media Status Notification feature set support
128 V 0021h Security status
129-159 X varies Vendor-specific
Table 17. Returned Sector Data (Continued)
Word
F = Fixed
V = Variable
X = Both
Default Value Description
