2.3 Electrical Characteristics
Notes:
1. Active power measured during execution of MobileMark* 2007 with SATA Link Power Management (LPM) enabled.
2. Idle power defined as SSD at idle with SATA Link Power Management (LPM) enabled.
2.4 Environmental Conditions
Notes:
1. Temperature gradient measured without condensation.
2. Shock specifications assume the SSD is mounted securely with the input vibration applied to the drive-mounting screws.
Stimulus may be applied in the X, Y or Z axis. Shock specification is measured using Root Mean Squared (RMS) value.
3. Vibration specifications assume the SSD is mounted securely with the input vibration applied to the drive-mounting
screws. Stimulus may be applied in the X, Y or Z axis. Vibration specification is measured using Root Mean Squared (RMS)
value.
Table 5. Operating Voltage and Power Consumption
Electrical Characteristics Value
Operating Voltage for 5 V (±5%)
Min
Max
4.75 V
5.25 V
Power Consumption (TYP)
Active
1
Idle
2
850 mW
600 mW
Table 6. Temperature, Shock, Vibration
Temperature Range
Case Temperature
Operating
Non-operating
0 – 70
o
C
-55 – 95
o
C
Temperature Gradient
1
Operating
Non-operating
30 (TYP)
o
C/hr
30 (TYP)
o
C/hr
Humidity
Operating
Non-operating
5 – 95 %
5 – 95 %
Shock and Vibration Range
Shock
2
Operating
Non-operating
1,500 G (Max) at 0.5 msec
1,500 G (Max) at 0.5 msec
Vibration
3
Operating
Non-operating
2.17 G
RMS
(5-700 Hz) Max
3.13 G
RMS
(5-800 Hz) Max
