6: Using The Motherboard
User’s Manual
6•1
In This Chapter:
Using System Features
Front Panel Controls & Indicators
Additional System Features
Installing & Configuring An IR Port
Performance Optimization
Troubleshooting
6: Using the Motherboard
This chapter covers several topics related to using this
motherboard once it is installed in a working system.
These include external system features that connect to
the motherboard, things you can do to optimize the per-
formance of a system based on this board and some
troubleshooting tips you can review in the event any prob-
lems arise.
Using System Features
This section explains the system controls and indicators
that connect to the motherboard. It also explains how
the other system level features on the board work.
Front Panel System Controls & Indicators
The front panel of the system housing will have some or
all of the front panel features that connect to the
motherboard. These enable the User to determine some
information on the systems operational status and pro-
vide some system controls.
System Controls
The front panel connector on the motherboard supports
several system controls that mount on the front panel of
the system housing.
