10 Digikey sources
Figure 9 shows some third-party accessories you can use.
Figure 9 Digikey sources
Mating connector 2.0 mm
DF40C(2.0)-70DS-0.4V(51) - H11908CT-ND
Cut tape
DF40C(2.0)-70DS-0.4V(51) H11908TR-ND Tape and Reelt
Mini-breakout power jack PJ-002BH-SMT-TR
CP-002BHPJCT-ND Cut tape
PJ-002BH-SMT-TR CP-002BHPJTR-ND
Tape and reel
Mini-breakout USB adapter cable
USB A female to Micro A male 10-00649 839-1105-ND
Mini-breakout male header
2x14 M20-9980745 952-1932-ND
§
