Intel Desktop Board DQ57TML Product Guide
10
Table 1. Feature Summary (continued)
Peripheral
Interfaces
• Twelve USB 2.0 ports:
― Four ports are implemented with back panel connectors
― Eight ports are implemented with four dual-port internal headers
(one header supports an Intel
®
Z-U130 USB Solid-state Drive or
compatible device)
• Four onboard Serial ATA (SATA) 3.0 Gb/s ports
• One back panel parallel port connector
• One serial port header
• One PS/2 back panel connector for mouse/keyboard support
LAN Support Intel
®
82578DM Gigabit (10/100/1000 Mb/s) Ethernet LAN controller
with support for:
• Intel
®
Active Management Technology (Intel
®
AMT) 6.0
• ASF 2.0
BIOS
• Intel
®
BIOS resident in an SPI Flash device
• Support for Advanced Configuration and Power Interface (ACPI),
Plug and Play, and SMBIOS
Instantly Available
PC Technology
• Support for PCI Local Bus Specification, Revision 2.2
• Support for PCI Express Base Specification, Revision 2.0
• Suspend to RAM support
• Wake on PCI, PCI Express, LAN, front panel, serial, PS/2, and USB
ports
Hardware
Monitoring
• Intel
®
Quiet System Technology (Intel
®
QST) implemented through
the Intel
®
Management Engine (Intel
®
ME) in the Intel Q57 PCH
• Voltage sense to detect out of range power supply voltages
• Thermal sense to detect out of range thermal values
• Three fan headers using PWM control
• 4-pin headers for processor, front chassis, and rear chassis fans
• 4-wire and 3-wire (linear) fan speed control support for front and
rear chassis fans
• Support for Platform Environmental Control Interface (PECI)
Intel
®
vPro™
Technology
• Intel
®
Advanced Management Technology (Intel
®
AMT) 6.0
• Intel
®
Trusted Execution Technology (Intel
®
TXT)
• Intel
®
Remote PC Assist (Intel
®
RPAT)
• Intel
®
Fast Call for Help
• Intel
®
Virtualization Technology (Intel
®
VT)
• Intel
®
Virtualization for Directed I/O (Intel
®
VT-d)
