Intel Desktop Board DP55WG Technical Product Specification

Intel Desktop Board DP55WG Technical Product Specification
42
Table 9. Component-side Connectors and Headers Shown in Figure 11
Item/callout
from Figure 11 Descript
ion
A PCI bus connector
B PCI Express 2.0 x4 connector
C PCI bus connector
D PCI Express 2.0 x8 connector
E Front panel audio header
F S/PDIF header
G PCI Express 2.0 x1 connector
H Rear chassis fan header
I PCI Express 2.0 x1 connector
J PCI Express 2.0 x16 connector
K 12 V processor core voltage connector (2 x 4)
L Processor fan header
M Main power connector (2 x 12)
N Front panel header
O Back panel CIR transmitter (output) header
P Front panel CIR receiver (input) header
Q Alternate front panel power LED header
R Front chassis fan header
S USB 2.0 header
T USB 2.0 header
U IEEE 1394a header
V Serial ATA connectors
W Chassis intrusion header
X USB 2.0 header
Y Auxiliary PCI Express graphics power connector (SATA-style)
