Intel Desktop Board DP55WG Technical Product Specification

Product Description
29
1.12.1.2 Wake-up Devices and Events
Table 7 lists the devices or specific events that can wake the computer from specific
states.
Table 7. Wake-up Devices and Events
These devices/events can wake up the computer… …from this state
Power switch S1, S3, S4, S5
(
Note 1)
RTC alarm S1, S3, S4, S5
(Note 1)
LAN S1, S3, S4, S5
(Note 1)
USB S1, S3
PME# signal S1, S3, S4, S5
(Note 1)
WAKE# S1, S3, S4, S5
(Note 1)
Consumer IR S3, S4, S5
(Note 2)
Notes:
1. S4 implies operating system support only.
2. Wake from S4 and S5 is recommended by Microsoft.
NOTE
The use of these wake-up events from an ACPI state requires an operating system
that provides full ACPI support. In addition, software, drivers, and peripherals must
fully support ACPI wake events.
