Intel Desktop Board DP55WG Technical Product Specification

Intel Desktop Board DP55WG Technical Product Specification
12
Table 2. Components Shown in Figure 1
Item/callout
from Figure 1 Descript
ion
A PCI bus connector
B PCI Express 2.0 x4 connector
C PCI bus connector
D PCI Express 2.0 x8 connector
E Front panel audio header
F S/PDIF header
G PCI Express 2.0 x1 connector
H Rear chassis fan header
I PCI Express 2.0 x1 connector
J PCI Express 2.0 x16 connector
K Battery
L Back panel connectors
M 12 V processor core voltage connector (2 x 4)
N Processor fan header
O Processor LED (red)
P Voltage regulator LED (red)
Q Processor socket
R POST code LED display
S DIMM Channel A socket
T DIMM Channel B socket
U Onboard power button
V Standby power indicator LED (green)
W Main power connector (2 x 12)
X SATA drive activity LED (blue)
Y Front panel header
Z Back panel CIR emitter (output) header
AA Front panel CIR receiver (input) header
BB Alternate front panel power LED header
CC Front chassis fan header
DD USB 2.0 headers (2)
EE IEEE 1394a header
FF Intel P55 Express Chipset
GG BIOS configuration jumper block
HH Serial ATA connectors
II Chassis intrusion header
JJ USB 2.0 header
KK Speaker
LL Auxiliary PCI Express graphics power connector (SATA-style)
